اسم المنتج: Planing and sawing machine ML9620M
طلب: Cut and plan for anticorrosive woods
عرض العمل: 20-200مم
سمك العمل: 10-125مم
مغزل: 6
سرعة التغذية: 5-25م/بلدي
| تحديد | ML9620HM | ML9620M | ML9620SMF | ML9616SM | |
|---|---|---|---|---|---|
| عرض العمل | مم | 20-200 | 20-200 | 20-200 | 35-160 |
| سمك العمل | مم | 10-200 | 10-125 | 10-120 | 15-120 |
| دقيقة. طول العمل | مم | 550/480 | 650/480 | 650/480 | 650/480 |
| Saw spindle Dia. | مم | φ50 | φ40 | φ50 | φ50 |
| Saw spindle speed | ص/دقيقة | 4500 | 4500 | 4000 | 4000 |
| Planer spindle dia. | مم | φ40 | φ40 | φ40 | φ40 |
| Planer spindle speed | ص/دقيقة | 6800 | 6800 | 6800 | 6800/8000 |
| سرعة التغذية | م/بلدي | 5-25 | 5-25 | 6-30 | 6-30 |
| القوة الكلية | KW/HP | 94.5/126 | 82.25/110 | 72.75/97 | 58.25/80 |
| شفط غطاء محرك السيارة. | مم | 3*φ150+4*φ120 | 3*φ150+4*φ120 | 6*φ150 | 2*φ150+4*φ120 |
| Overall dimension | مم | 4580*1800*1750 | 4530*1680*1630 | 4420*1790*1750 | 4170*1530*1720 |
| وزن | كجم | 4600 | 4300 | 4850 | 3750 |
1. The movable worktable adopts the structure of cylinder floating double active rollers, and the feeding is smooth and powerful.
2. The movable limit bar has a built-in rolling bearing, which makes the feeding smoother.
3. The upper and lower saw shafts are equipped with a blowing mist cooling mechanism to cool the saw blade. The saw blade has good heat dissipation, good precision retention and high durability.
4. The feeding mechanism adopts imported frequency converter for speed regulation and universal joint transmission, which is convenient for adjustment and stable in feeding.
5. The saw shaft is made of special material with a diameter of φ40mm, and the saw blade can be directly installed on the saw shaft without a reducing sleeve. Small diameter and thin saw path lead to material saving.
Professional solution for the solid wood processing industry for sauna panels, wall panels, floor panels and bedding panels.It is a planing saw machine that combines a four-sided planer with a left and right vertical axis multi-blade saw.It can simultaneously carry out the four-sided moulding and planing of the square material and the left and right vertical axis slice sawing and slicing operations.المزايا: high production efficiency, material saving in processing and good quality of processed flakes.
customized table
طاولة التغذية الخاصة بنا 4 يمكن إطالة المتناسقة الجانبية, طول مخصص وفقًا لمتطلباتك.
customized Motor
في جدول المعلمات الفنية لدينا 4 سوي على الوجهين متلهف, يمكنك رؤية التكوين القياسي لدينا. إذا كنت بحاجة, يمكننا ترقية طاقة المحرك لك.
Conveyor system
من أجل توفير تكلفة العمالة وتحسين الإنتاجية لك, يمكننا الجمع 4 تم تجهيز مستوي لكم مع نظام التغذية والتغذية الخارجية.
أدوات القطع
لا تحتوي معظم آلات النجارة الخشبية على أدوات القطع عند التصدير, لأن مصانع النجارة المختلفة تحتاج إلى نوع مختلف من القواطع. لتحسين خدمتنا, يمكننا مساعدتك في شراء أدوات القطع.
ENTIRE CAST IRON
Extra heavy one-piece, cast Iron machine frame is specially heat treated for maximum stability and rigidity by standard configuration.
ANTI-REBOUND SAFETY DEVICE
The anti-rebound safety device located on the infeed ensures operational safety.
Wear resistance guide track
The casting guide track and chain plate are made of special materials, specially processed and precisely processed, with high surface hardness, high precision and good wear resistance
Automatic lubricator
The automatic lubricator delivers frequent lubrication oil to the caterpillar chain.
Dust Removal Brush
The dust removal brush made of special materials is matched with a quantitative oil injection device to clean and lubricate the chain plates in real time
HIGH PRECISION SPINDLE
All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy.
PROFESSIONAL ELECTRICAL APPLIANCES
Siemens and Schneider electrical products and appliances insure the whole machine run well with a stable performance
CAST IRON CHROMED FEED TABLE
The entire Cast Iron – Chromed Infeed table is normalization heat treated for maximum stability. Infeed Table & Fence adjustment is quickly accomplished by means of a quick-setting levers.
