Technical PARAMETERS DETAILS
| Description | ||||
|---|---|---|---|---|
| Model | QSP60-400 | ZSP80-400 | TZSP100-400 | ZSP100-750 |
| Log dia. | 100-600mm | 100-800mm | 100-1000mm | 100-1000mm |
| Log length | 1200-4000mm | 1500-4000mm | 1500-4000mm | 1500-7500mm |
| Cutting thickness | ≥3mm | ≥3mm | ≥3mm | ≥3mm |
| Cutting speed | 1-35m/min | 1-35m/min | 1-35m/min | 1-35m/min |
| Return speed | 50m/min | 40m/min | 40m/min | 40m/min |
| Heavy Duty CNC Auto Carriage Nachine Power | 8kw | 18.4kw | 19.4kw | 19.4kw |
| Wood Log Conveyor System Power | 4kw | 9.2kw | 10.3kw | 10.3kw |
| Log Discharge Roller Conwyor System Power | 2.2kw | 4.4kw | 6kw | 6kw |
YOUTUBE VIDEo
1. Suitable for large diameter and special-shaped wood processing
2. Auto carriage the straight track is used on one side of the longitudinal direction,soas to ensure that the longitudinal movement is straightness.
3. The combination of rack and servo motor is used for size setting to ensure accuracy,rapidity and stability.
4. Using plc and touch screen,the operation is simple,humanized and common.
5. Using hydraulic system,log clamp,swinging head block and log turning
log turning system
Log discharge roller
Log converyor system
Heavy duty wheel
