Product Name: Multi Blade Gang Rip Saw QMJ143F
Application: multi-blade wood ripping cutting sawing
Max. Working Width:300mm
Working Thickness: 10-120mm
Min. working length: 585/300mm
Feeding Speed: 4-30m/min
The LENOX® Metal Cutting Circular Saw Blade is a faster way to cut metal. The Blade is titanium nitride coated carbide tipped which resists material build up. The Blade also provides less burring than abrasive blades, which eliminates the need for secondary grinding and reduces material burning.
| Specifications | QMJ145H | QMJ143S | QMJ143E | QMJ143F | |
|---|---|---|---|---|---|
| Max. working width | mm | 500 | 300 | 300 | 300 |
| Working thickness | mm | 10-170 | 10-85 | 10-120 | 10-120 |
| Min. working length | mm | 740 | 530/200 | 600/300 | 585/300 |
| Saw spindle dia. | mm | φ60 | φ55 | φ55 | φ55 |
| Reducing sleeve dia. | mm | φ80 | φ70 | φ70 | φ70 |
| Saw spindle speed | r/min | 2600 | 4000 | 4000 | 4000 |
| Feeding speed | m/min | 3-24 | 4-30 | 4-30 | 4-30 |
| Total power | kW/HP | 81.25/109 | 32.57/43.5 | 39.57/52.7 | 39.57/52.7 |
| Suction hood dia. | mm | 2*φ150 | 2*φ150 | 2*φ150 | 2*φ150 |
| Overall dimensions | mm | 4850*2020*1880 | 1930*1580*1560 | 2200*1500*1580 | 4460*1570*1600 |
| Weight | kg | 4250 | 2250 | 2300 | 2300 |
ENTIRE CAST IRON
Extra heavy one-piece, cast Iron machine frame is specially heat treated for maximum stability and rigidity by standard configuration.
ANTI-REBOUND SAFETY DEVICE
The anti-rebound safety device located on the infeed ensures operational safety.
Wear resistance guide track
The casting guide track and chain plate are made of special materials, specially processed and precisely processed, with high surface hardness, high precision and good wear resistance
Automatic lubricator
The automatic lubricator delivers frequent lubrication oil to the caterpillar chain.
Dust Removal Brush
The dust removal brush made of special materials is matched with a quantitative oil injection device to clean and lubricate the chain plates in real time
HIGH PRECISION SPINDLE
All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy.
PROFESSIONAL ELECTRICAL APPLIANCES
Siemens and Schneider electrical products and appliances insure the whole machine run well with a stable performance
CAST IRON CHROMED FEED TABLE
The entire Cast Iron – Chromed Infeed table is normalization heat treated for maximum stability. Infeed Table & Fence adjustment is quickly accomplished by means of a quick-setting levers.
